SilverLine Sliding Gate

An Aesthetic Showcase For Your Driveway

No matter if you choose an anodised surface or a powder coating, the INOVA SilverLine sliding gate makes a stunning visual impression. This elegant sliding gate blends in with every driveway, without being obtrusive. The distinctive silver lining along the middle of the upper and lower beams give the SilverLine sliding gate a unique design.

Highlights

• aesthetic and modern design to create a prestigious • stable, cantilevered aluminium construction designed for car and truck entrances with normal traffic frequency • opening width of 13 meters, no bottom rail required • INOVA drive unit is housed invisibly inside the lower beam and protected from weather and tampering • extensive basic equipment and a complementary selection of optional extras • gate system is pre-assembled and ready for immediate operation
Basic Specification

• modular aluminium construction with bar infill • 6 contact strips and 2 photoelectric switches for maximum accident prevention • drive power of up to 0.37 kW, integrated in the lower beam • anodised aluminium surface or powder coating in the standard RAL colours (6005, 7016, 7030, 9010) • the high opening/closing speed of 25 cm/s allows short opening and closing cycles
Optional Extras

• anti-climb spikes serving as additional intrusion protection (starting at 1.8 meters gate height) • induction loop for automatic gate opening/closing • weekly timer for automatic opening/closing of the gate at fixed times • flashing light or LED revolving signal beacon to signal gate movement • anti-wear strip on the upper beam to protect the powder coating • fence connection and pedestrian side gate, matching the gate height • almost unlimited choice of special colours

In case you require a gate with additional features or properties, please also look at our line of INOVA Industrial sliding gates. Click here to find a detailed comparison of our different lines of INOVA sliding gates.

Increased Economic Efficiency Through Automation

The series production of INOVA SilverLine aluminium sliding gates is a highly automated and very cost-effective process. The gates are manufactured as a patented modular screw design. Instead of using large and expensive aluminium profiles, as done with conventional aluminum sliding doors, the lower beam profile of the INOVA SilverLine gate is made up of a small number of combined profiles, that are lightweight and therefore cost-effective. Nevertheless, SilverLine sliding gates are high-strength constructions that allow opening widths of up to 13 meters.
